Technical specifications
- InterfaceDigital Inputs: 1
- Digital Outputs1
- Analog Inputs1
- GNSS AntennaInternal High Gain
- Cellular AntennaInternal High Gain GSM
- USB2.0 Micro-USB
- LED indication2 Status Indicator LEDs
- Speed accuracy< 0.1 m/s (error +/- 15%)
- SIMMicro-SIM
- MemoryInternal Flash Memory 128MB
- Weight50
- Power supplyInput voltage range: 6-30 Constant current with surge protection
- Required powerAt 12 V < 2 mA (Ultra Deep Sleep); At 12V < 4 mA (Deep sleep); At 12V < 5 mA (sleep mode); At 12V < 6 mA (GPS Sleep); At 12V < 35 mA (nominal)
- Dimensions79 x 43 x 12 mm
- Storage temperature-40 °C to +85 °C
- Operating conditions / HousingOperating temperature: -40 °C to +85 °C
- Operating humidityfrom 5% to 95% without condensation
- Housing protection levelIP54
- BluetoothSpecification: 4.0 + LE
- Supported PeripheralsTemperature and Humidity Sensor, Headset, OBDII dongle, Inateck Barcode Scanner, Support for universal BLE sensors
- GNSS / ConnectivityGNSS: GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS, DGPS, AGPS
- Display sensitivity165 dBm
- Receiver33 channel
- Positioning accuracy< 2.5m CEP
- Hot Start< 1 s
- Warm Start< 25 s
- Cold Start< 35 s
- Data ExchangeGPRS Multi-Slot Class 12 (up to 240 kbit/s), Class B GPRS mobile station
- Network2G-bands: Quad-band module 850/900/1800/1900 MHz
- Data SupportSMS (text/data)
- ModuleName: Teltonika TM2500
- TechnologyGSM/GPRS/GNSS/BLUETOOTH
- CertificationNorms: E/RED, E-Mark, EAC, RoHS, REACH
- FeaturesSensors: Accelerometer
- Dormant modesGPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
- Configuration and firmware updateFOTA WEB, FOTA, Teltonika Configurator (USB, Bluetooth®), FMBT Mobile App (Configuration)
- SMSConfiguration, Events, Management DOUT, Debug
- GPRS commandsConfiguration, Control DOUT, Debug
- Ignition EquipmentDigital Input 1, Accelerometer, External Voltage Question, Engine RPM (OBDII dongle)
- Time synchronizationGNSS, NITZ, NTP
- ScenariosEco Driving, Detection of Exceeds Speed, GSM Suppression Detection, GNSS Fuel Meter, DOUT Call Management, Excessive Idling Detection, Towing Detection, Accident Detection, Automatic Geofencing, Manual Geofencing, Trip Notification
- Fuel MonitoringLLS (Analog), OBDII dongle
