Technical specifications
- InterfaceUART: 1
- ConnectionNinebot's own 5-pin connector
- GNSS AntennaInternal High Gain
- Cellular AntennaInternal High Gain GSM
- USB2.0 Micro-USB
- LED indication2 LED Status Indicators
- Speed accuracy< 0.1 m/s (error +/- 15 %)
- SIMMicro-SIM
- MemoryInternal Flash Memory 128MB
- Sound indicationInternal buzzer
- Weight130
- Height70
- Length78
- Power supplyInput voltage range: 8-50V
- Internal backup batteryLithium-ion battery with a capacity of 170 mAh, 3.7 V (0.63 Wh)
- Dimensions78 x 75 x 70 mm
- Operating conditions / HousingOperating temperature (without battery): from -20 °C to +75 °C
- Storage temperature (without battery)from -20 °C to +75 °C
- Operating humidityfrom 5% to 95% without condensation
- Housing protection levelIP65
- Battery charge temperaturefrom 0 °C to +45 °C
- Battery discharge temperaturefrom -20 °C to +60 °C
- Battery Storage Temperaturefrom -20 °C to +45 °C within 1 month; from -20 °C to +35 °C for 6 months
- Width75
- BluetoothSpecification: 4.0+LE
- Supported PeripheralsSensors ELA, EYE Sensors, EYE Beacons, Solebe Y905 lock
- GNSS / ConnectivityGNSS: GPS, GLONASS, GALILEO, BEIDOU, SBAS, QZSS
- Receiver33 channel
- Location Accuracy< 2.5m CEP
- Hot Start< 1 s
- Tracking Sensitivity165 dBm
- Warm Start< 25 s
- Cold Start< 35 s
- Data ExchangeGPRS Multi-Slot Class 12 (up to 85.6 kbps), Class B GPRS mobile station
- NetworkTechnology: GSM/GPRS
- 2G BandsQuad-band module 850/900/1800/1900 MHz
- Data SupportSMS (text/data)
- ModuleName: Teltonika TM2500
- TechnologyGSM/GPRS/GNSS/BLUETOOTH
- CertificationStandards: CE (RED), EAC, Ukrainian UCRF, UKCA, RoHS, REACH, IP65
- FeaturesScenarios: Jamming, Unauthorized movement detection, FallDown, Unplug Detection, SIM Card Tamper Protection, Last Known Position, Auto Geofence, Manual Geofence, Trip/Odometer, BT lock support
- SensorsAccelerometer
- Dormant modesGPS Sleep, Online Deep Sleep
- Configuration and firmware updateFOTA Web, Teltonika Configurator (USB, Bluetooth®)
- SMSConfiguration, Events, Debugging
- GPRS commandsConfiguration, Debugging
- Time synchronizationGNSS, NITZ, NTP
- Ignition detectionHeader Scooter Lock
